Max bag width 950mm
Max bag length depth 900mm
Max unwinding diameter f1000mm
Max speed pcs/min 40-150 pcs/min depending on the bag size
Weight: 5000kg
Dimension L W H : 8000 1700 2000mm
Voltage :380V, 50Hz

Inverter control speed, easy to operate, reduce electric consumption.
Feed wheel and pull device controlled by servo motor, high efficiency output.
Computer control full automatically, touch screen and human-machine interface, easy for correction and fine adjustment.
Unwinding adopts shaft feeding, equipped with 3 raised key type air expansion shaft
Unwinding with 2.5kg magnetic powder brake
The deviation rectifying device is a push-type photoelectric automatic deviation
rectifying device.
8. Glue scraping and merging function part
1 Longitudinal Z-axis servo motor: 1 piece
2 Glue scraping of transverse X-axis servo motor: 2piece
3 Centrifugal membrane glue gun: 1 piece
4 Rubber scraping can be moved left and right: 1 set
5 Bottom scraping can move left and right: 1 set
6 Glue storage barrel

Photocell         Datalogic – Italy
Servo motor driver   Mitsubishi – Japan
Inverter Delta –Taiwan
PLC with program   Mitsubishi – Japan
Touch screen          MCGS– Taiwan
Tension controller Automatic
Button Schneider – France
Bearing NSK--Japan
SSR Fotek - Taiwan
Intermediate relay Schneider – France
