CMC PROFI-LINE R-320
Rotary / Semi-Rotary Label Die-Cutting & Finishing Machine
320 mm | Servo Technology | Register Die-Cutting | Rewinding | Professional Label Finishing
Dear Sir or Madam,
we are pleased to offer the following CMC PROFI-LINE R-320, a professional rotary die-cutting and label finishing machine designed for the converting of self-adhesive labels and narrow-web materials.
The machine was manufactured in 2016 and offers a compact but highly functional configuration for professional label production.
With a working width in the 320 mm class, servo-controlled web transport, register-controlled die-cutting and several winding positions, the machine represents an attractive solution for label converters looking for a flexible finishing system for digitally or conventionally printed label material.
The machine is currently installed and can be inspected by prior appointment.
________________________________________
MACHINE DETAILS
Manufacturer: CMC Maschinenbau GmbH
Model: PROFI-LINE R-320
Machine type: Rotary Die-Cutting / Label Finishing Machine
Year: 2016
Machine No.: 100 586
Working width: approx. 320 mm class
Electrical supply: 400 V
Frequency: 50 Hz
Installed power: 20.5 kW
Maximum machine speed according to machine plate: 90 m/min
Machine weight: approx. 1,800 kg
CE marked
________________________________________
DIE-CUTTING SYSTEM
The machine is equipped with a professional rotary die-cutting section suitable for the finishing of printed self-adhesive label materials.
Visible equipment includes:
• Rotary die-cutting station
• Magnetic cylinder system
• Counter-pressure cylinder
• Adjustable die pressure
• Heavy-duty die-cutting frame
• Servo-controlled material transport
• Register-controlled production
• Suitable for printed label webs
• Matrix / waste separation
The machine is particularly suitable for the finishing of digitally printed labels where precise die-cutting registration is required.
________________________________________
REGISTER CONTROL
The machine is equipped for register-controlled operation, allowing the die-cutting process to follow pre-printed material.
This makes the machine suitable for:
• Digital label production
• Flexographically printed labels
• Pre-printed self-adhesive materials
• Short- and medium-run label finishing
The servo-controlled system helps maintain stable web positioning during production.
________________________________________
WEB HANDLING
The machine is equipped with an extensive web path and several web-handling components.
Visible on the machine:
• Electronic web guiding system
• Web guide sensor
• Multiple guide rollers
• Controlled material feed
• Adjustable web tension
• Pneumatic shafts
• Several rewinding / waste winding positions
The web guiding system contributes to precise material alignment before and during the die-cutting process.
________________________________________
UNWINDING
The machine includes a professional unwind section for roll-fed production.
Features visible on the machine include:
• Pneumatic unwind shaft
• Roll-fed material handling
• Controlled web tension
• Adjustable web path
• Material guiding system
The machine is suitable for typical labelstock, paper and film-based self-adhesive materials.
________________________________________
REWINDING
A major advantage of this machine is the flexible winding configuration.
The machine features several pneumatic winding shafts which allow finished material and production waste to be handled separately.
Suitable for:
• Finished label roll rewinding
• Matrix waste rewinding
• Different roll configurations
• Roll-to-roll finishing
________________________________________
MATRIX WASTE REMOVAL
The machine is equipped for the removal of die-cutting matrix waste after the label has been cut.
This is an important production feature for self-adhesive label finishing.
The waste matrix can be separated and rewound independently from the finished label material.
________________________________________
SLITTING / FINISHING AREA
The machine appears to include a finishing / slitting area with adjustable components for roll conversion.
Depending on the installed tooling, the machine can be used for:
• Longitudinal slitting
• Multiple finished rolls
• Narrow roll production
• Conversion of wider printed webs
The exact number and type of slitting knives should be confirmed during inspection.
________________________________________
TOUCHSCREEN CONTROL
The machine features an electronic touchscreen control system.
The operator interface allows machine parameters to be controlled directly from the central operating panel.
Visible control functions include:
• Machine start / stop
• Jog / inching function
• Production speed control
• Web tension settings
• Rewinding control
• Register / die-cutting functions
• Individual drive controls
The machine also includes conventional operating controls and emergency stop buttons for safe production.
________________________________________
SERVO TECHNOLOGY
The machine uses servo-controlled drive technology for the handling and positioning of the web.
Advantages include:
• High registration accuracy
• Stable web transport
• Precise acceleration and deceleration
• Controlled winding tension
• Improved repeatability
• Suitable for short-run digital label finishing
________________________________________
APPLICATIONS
The CMC PROFI-LINE R-320 is suitable for a wide range of label converting applications, including:
• Self-adhesive labels
• Digital labels
• Paper labels
• Film labels
• Roll labels
• Pre-printed materials
• Short-run label production
• Medium production runs
• Die-cutting and rewinding
• Matrix stripping
• Roll-to-roll converting
________________________________________
KEY ADVANTAGES OF THIS MACHINE
Professional 320 mm Label Finishing Platform
The PROFI-LINE R-320 offers a compact production solution for converting digitally or conventionally printed label rolls.
Register-Controlled Die-Cutting
An important advantage for digital label production, where precise positioning of the die-cutting tool relative to the printed image is essential.
Servo-Controlled Web Transport
Servo technology provides precise web movement and consistent production quality.
Flexible Rewinding Configuration
Several winding positions allow finished material and waste to be handled efficiently.
Compact Machine Design
The machine combines important converting processes within one relatively compact platform and is particularly interesting for label converters with limited production space.
Strong Alternative to New Equipment
For companies looking to expand their finishing capacity without investing in a new machine, this CMC represents an interesting and cost-effective solution.
