Maximum film width: 1350 mm

Coating width: max. 1300 mm

Mechanical speed: 305 m/minute

Materials to be coated: BOPP 18-40 microns, PA 12-30 microns, PET 12-24 microns, Paper 60-100 gr/sqm, Laminates 60-100 gr/sqm

Materials to be laminated: BOPP 12-40 microns, CPP 12-40 microns, PA 12-30 microns, CPA 12-30 microns, LDPE 20-120 microns, PET 12-24 microns, ALU FOIL 9-18  microns, Paper 40-80 gr/m2, Laminates 40-80 gr/m2

From left to right

First unwinder reel diameter: 800 mm

Secondary unwinder reel diameter: 800 mm

Tension range: 1,5 - 34 kg

Rewinder diameter: 800 mm

Reel shafts: pneumatic

Core diameter: 76 m
