No delam relam

Mechanical drive on printing units and servo drive on die cutting stations

Front load unwinder with motorized roll lifting

Unwinder with magnetic particle clutch max. reel diameter 1.000 mm.

BST Automatic Web Guide

BST Powerscope web viewing system with manual camera movement

Infeed unit

2 Die-cutting stations male-female die-cutting possible

Servo driven die-cutting units 1 servo motor per unit

Waste matrix rewinder up to 700 mm diameter

Crush cutting slitting system including 3 blades

Back slitting unit for silicon paper half cut Includes 2 crush knives

Outfeed unit

Vario™ - Servo driven outfeed includes active load cell

Organizer includes crane to remove and store die-cutting tools

3 Web break detectors 2 for main web, 1 for matrix web

Motorized rewinder max. reel diameter 1.000 mm.

Local touch screen panel on each printing and die-cutting station

Main touch screen panel PC HMI

Direct Internet Connection for remote SW and HW service and upgrades

Flexo Printing Unit Description

Mechanical drive with rigid transmission for the printing units

Includes:

1000 mm base platforms for up to 2 Flower™ flexographic heads

Flower™ flexographic heads

Short web path

Plexiglass cover for printing unit

GEW UV curing system with E2C 140W/cm lamps and RLT electronic power supply. Include main touch screen panel

Printing accessories:

1 set of rubber rollers per color 3 additional pcs.

1 set of ink trays per color 3 additional pcs.

1 set of doctor blade holders per color 3 additional pcs.

SnowBall™Lite: The system is based on a rewind architecture which obliges the waste to rewind on a fixed point, to create a stable and reliable build-up of a “snow-ball” of waste matrix. The system includes : waste rewind stripping device, on linear horizontal guides, includes rewind motors pressure pneumatic cylinder and pneumatic shaft. Maximum waste reel diameter mm. 700.

LaserSet™ Pre-register system through the use of a laser pointer which guides the operator to the correct angular position of the print cylinder as indicated by the local touch screen panel.

10 colors

Temperature and Tension Control

Bobst recommends chilled drums for press configuration over 8 print units

Vario : Infeed unit driven by servo motor

Chilled drum excluding pipes and chilling unit - Installed in lower position

Max 2 units before die-cutting and/or mid press can be selected.

Chilling Unit for up to 8 chill drums

Die-cutting and matrix removal

Additional blade for crush cutting or for back slitting

Rail system for accessories

Upper rail for 2 printing units module

Eg. Select 4 for 7 or 8 color press.

Combo Laminator unwinder and rewinder and Cold Foil kit on RAIL

Peristaltic ink pump- 1 pc.

Additional ink tray with rubber roller and doctor blade holder - 3 pcs.

Corona treaters:

Vetaphone 3 kW; DG 30 fan; 6 bars single side head application frame and installation included

Web Cleaners:

ACE double side non-contact type
